Chiller Unit Three-phase – Inverter BLDC

New 130K and 180K BTU/h versions

Refrigeration unit with BLDC inverter technology
for central air conditioning systems.

Three-phase Power Supply

CU Series Enhancements

  • Improved efficiency
  • Machine weight reduction
  • Reduced fuel consumption both in ECO mode and at full capacity
  • New versions with Titanium seawater exchanger
FRIGOMAR Chiller CU Series 90K-130K-180K BTU

Simple and intuitive touch-screen display.

1 of 4

Ready for installation
of the touch-screen in other positions

2 of 4

Fastening point for transportation

3 of 4

Panels with internal thermoacustic insulation

4 of 4
90,000 BTU/hr
CU90VFD-U
Cupro-Nickel
230 V
CU90VFDT-U NEW
Titanium
230 V
CU90VFD
Cupro-Nickel
400 V
CU90VFDT NEW
Titanium
400 V
130.000 BTU/h
CU130VFD NEW
Cupro-Nickel
400 V
CU130VFDT NEW
Titanium
400 V
180.000 BTU/h
CU180VFD NEW
Cupro-Nickel
400 V
CU180VFDT NEW
Titanium
400 V

Chiller Unitsmore efficient and innovative

  • Compact and lightweight design
  • 50% higher energy efficiency compared to ON/OFF
  • Highest comfort: silent operation and stable temperature
  • Low power consumption: 2400W max input power in ECO mode (CU-130)
  • Peak current suppression at start-up (5.5A max for CU130 only)

New generationThree-phase BLDC Inverter

Ideal for Yachts and Megayachts

Thanks to the cooling capacity of up to 180,000 BTU/h the three-phase Chiller units are able to meet the needs of Megayachts over 60 meters.

Our Chillers are modular thus making it simple to install them on board and crew maintenance operations, which is particularly useful when carrying out refits and refurbishments of old plants.

Cu-Ni 70/30

Our CU refrigeration units use a special sea water condenser made of Cu-Ni 70/30, a material that offers excellent anti-erosion and anti-corrosion qualities.

The use of Cu-Ni 70/30 makes our chillers more resistant and durable.

Easy to install

The compact overall dimensions and low weight allow the installation on-board all types of boat.

NT-Display
Luca Stauder designer
609NT-detail
Luca Stauder designer
FRIGOMAR Chiller CU Series 90K-130K-180K BTU

Chiller Technology

The Chiller system is undoubtedly the preferred choice for on-board air conditioning systems, offering a number of key benefits:

  1. Simple installation
  2. Closed and factory tested Refrigerant Gas system
  3. Reduced quantity of Refrigerant Gas
  4. Ease of Maintenance

Frigomar has invested significant resources in the development and optimization of its exclusive BLDC Inverter technology, and has succeeded in producing units that are more and more efficient and that offer increasingly greater performance: discover all the details of the Chiller system…

// Chiller Technology

Technical Specifications

CU90VFD-U
CU90VFDT-U
CU90VFD
CU90VFDT
Heat exchanger
Cupro-Nickel
Titanium
Cupro-Nickel
Titanium
Width
540 mm
Height
670 mm
Depth
600 mm
Weight
115 Kg
102 Kg
115 Kg
102 Kg
Voltage / phase / frequency
230 V / 3ph / 50-60 Hz
400 V / 3ph / 50-60 Hz
Maximum cooling/heating capacity
90,000 BTU/h – 15 ton
Maximum input power
7,5 kW
Maximum current
20 A
12,6 A
Input power
in ECO mode
2,35 kW
Maximum current in ECO mode
8,6 A
5.4 A
R410A refrigerant gas
2.20 kg
Operating Limits
Sea water temperature for heating
> 5°C / 41° F
Sea water temperature for cooling
< 40°C / 104° F
